Fully Adjustable Hydraulic Downfeed With Separate On/Off Control Valve
2 HP, 1Ph, 230 volt motor, automatic shut-off after cut
Four speeds: 82, 132, 210 and 330 FPM
Miter head swivels from 90° to 45° while the stock remains in the same position
Large easy-to-read scale for positioning saw head
Coolant is distributed through the carbide blade guides with roller bearings
Blade brush is built-in and self-propelled
14" wheel diameter, accepts blades 130" long x 1" wide, large handwheel and built-in gauge
blade tensioning
Cutting capacities:
Round at 90°: 10", at 45°: 9", rectangle at 90°: 10" x 14", at 45°: 9" X 8-1/2", vise swivels 45°
Liftgate delivery Required
Includes: saw, coolant system, (coolant not included), carbide blade guides with rollers
Adjustable material stop and one 1" x 4/6 variable tooth bi-metal blade
