Heavy-duty cast iron construction machined to strict tolerances
Hardened rolling shafts with bronze bushings
Foot-control for emergency stops
Equipped with six various size segment rolls for flat bar, square tubing and angle iron
Base comes with full storage cabinet
SPECIFICATIONS
1 HP, 230V, 3 Ph, shaft speed: 2 speed, 6/12 RPM
Bender Type: 3 roll pyramid style
Operating Positions: Vertical or horizontal
Pipe Capacity (schedule 40): 1", min. diameter .28"
Round Tube Capacity: 1-1/4", min. diameter 31-1/2"
Square Tube Capacity: 1-1/4", min. diameter 35"
Solid Round Capacity: 7/8", min. diameter 20"
Flat Bar Capacity- Easy Way: 2", min. diameter 15-3/4"
Flat Bar Capacity- Hard Way: 3/4", min. diameter 6-1/2"
Angle Iron Capacity: 1: 1-1/4", min. diameter.30"
Overall Dimensions: 31"L x 19-3/4"W x56"H
Weight: 606 lb.
