1-1/2 HP, 3 Ph, 230 volt, TEFC, two speed motor: 54 and 108 RPM, power cord is not included
Miters 45° left and 45° right
Blade size: 11" diameter x 1-1/4" arbor, .08" thick
Hardened and ground worm and wheel gear box
Control handle with a safety spring loaded trigger switch starts and stops the machine
Adjustable material length stop: 30", graduated
Adjustable jaw cam-handle vise, 4" maximum opening
Liftgate delivery required
Includes: saw, enclosed steel stand, blade, vise, and coolant system (coolant not included)
MACHINE SPECIFICATIONS
Cutting Capacities for Tubing
Round at 90°: 3-1/8"
Round at 45°: 3-1/8"
Rectangle at 90°: 3-1/32" x 2"
Rectangle at 45°: 2-1/16" x 2"
Square at 90°: 2-3/8" x 2-3/8"
Square at 45°: 2-1/16" x 2-1/16"
Cutting Capacities for Solid
Round at 90°: 1-3/8"
Round at 45°: 1-3/8"
Square at 90°: 3-1/32" x 2"
Square at 45°: 2-1/16" x 2"
Blade size (dia.): 11"
Coolant capacity: 1.3 gal.
Overall size: 39"W x 40"L x 72"H
Base Footprint: 23" x 24"
Weight: 330 lb
