3⁄4 HP, 115Vt, 1 Ph, TEFC motor • 16 variable speeds, 210-3,500 RPM
One-handed belt tensioning allows for rapid speed changes
Spindle travels a full 5" with one revolution of the handle
Xacta-X laser system easily identifies drill center
Long-lasting, built-in L.E.D. work light reduces shadows
Power switch features safety key and large, paddle-style off button
5⁄8" drill chuck with key
Machine Specifications:
Swing: 16-7⁄8", spindle travel: 5", spindle range: 210-3500
Chuck distance to table: 30", chuck distance to base: 42-7⁄8"
Table size: 14" x 19"
Column diameter: 3-5/32"
Weight: 187 lb.
