2 HP, 230 volt and 460 volt, 3 Ph models available
Two variable speed ranges, 65-540 RPM and 245-2,000 RPM
Front mounted L.E.D. spindle RPM readout and positive depth stop
Forward and reverse for instant tapping mode
Latest AC inverter variable speed technology
Heavy-duty casted head for more accuracy and rigidity
Large precision ground T-slot crank-operated production table for easy set-up, rotates and tilts 45°
Spindle supported by ball bearings reducing rotational friction while increasing load support
support
L.E.D. machine lamp delivers extra light for more precise drilling
Emergency stop allows for immediate shut-off
Standard equipment: spindle safety guard and L.E.D. machine lamp
Drills to Center of Circle: 20"
Drilling Capacity Cast-Iron: 1-1/2"
Drilling Capacity Mild Steel: 1-3/8"
Tapping Capacity Cast Iron:
Tapping Capacity Mild Steel:
Distance Column to Spindle: 10-7/16"
Number of spindle Speeds: Variable
Range of Spindle Speeds (RPM): 65-540/245-2,000
Column Diameter: 4-1/2"
Spindle Taper: MT-3
Spindle Travel: 6"
Spindle distance to Base: 44-1/2"
Spindle Distance to Table: 30-1/4"
Table Size (L x W): 22" x 14-3/4"
Working Table Area (L x W): 18-1/8" x 14-3/4"
Table Travel Effective Travel: 20"
T-Slots: 3 & 5/8"
T-Slot Centers: 7-7/16"
Work Table Weight Capacity: 154 lbs.
Base Dimensions: 27" x 19"
Base Work Area: 14-3/4" x 11-13/16"
Base Slots Number & Size:2 & 5/8"
Coolant System: Optional
Motor: 2HP, 230V, 3Ph
Inverter:2HP, 115V, 1Ph
Net Weight: 792 lbs.
