1.5 HP, 120/230V, 1 Ph, TEFC motor, pre-wired 120 volt
12 speeds, 150-4,200 RPM
Hinged metal belt and pulley cover allows access to spindle for speed changes
16-1⁄8" x 18-5⁄8" cast iron work table w/ “X" pattern mounting slots, tilts left or right 45 degrees
Adjustable tension spindle return spring
Push button switch is located on drill head
3⁄4" drill chuck and key is included
Safety shield
Machine Specifications:
Drilling catacity in steel: 1"
Swing: 20-1⁄2"
Spindle Travel: 4-5⁄8"
Spindle to Table: 29-1⁄8"
Spindle to Base: 46-3⁄4"
Table Size: 16-1⁄8" x 18-5⁄8"
Spindle Taper: MT-3
Column Diameter: 3-3⁄8"
Base Size: 13-5/8" x 22-3⁄8"
Weight: 288 lb.
