1.75 HP, 1 Ph, 115/230 volt motor
Variable speed range 50 - 3,000 RPM is default
Option in settings to increase to 5,500 RPM, forward and reverse
Intelligent speed selection ensures the correct speed for the application
Adjustable mechanical stop coupled with digital readout for accurate, repeatable drilling
Adaptive Control software is updatable via thumb-drive
5/8" drill chuck with key is included
Machine Specifications:
Swing: 18"
Spindle Travel: 6"
Spindle to Table: 23-1/8"
Spindle to Base: 40-15/16"
Table Size: 16-1/2"L x 16-1/2"W
Table Tilt: -45° to +45°, rotates 360°
Spindle Taper: MT2
Column Diameter: 3-5/8"
Base Size: 22-1/4"L x 17-1/2"W
Weight: 306 lb.
