1 HP, 115/230V, 1 Ph, TEFC motor, (pre-wired 115V)
Variable speed, 250-3,000 RPM with digital RPM readout
Mechanical variable speed adjustment allows for a full range of speeds with no belt changes
14" x 20" cast iron table with T-slots
Replaceable center insert with leveling screws, fence with adjustable stop
Table may be rotated to a full 90° position, tilts 0° to 90°
Laser guides provide an accurate indication for tool point
Two independent L.E.D. worklights eliminate shadows
5/8" keyled chuck, safety key prevents accidental starting
Machine Specifications:
Swing: 18"
Spindle Travel: 6"
Chuck distance to base: 43-13/32"
Chuck distance to table: 24-1/2"
Table size: 14" x 20"
Spindle taper: MT-2/JT-3
Column diameter: 3-1/8"
Fence size (L x H): 19-13/16" x 2-11/16"
Base size: 13-3/8" x 20"
Shipping weight: 246 lb.
