3/4 HP, 1 Ph, 115 volt motor
Variable speed range 210 - 3,500 RPM
Full 3-1/8" spindle travel with one handle revolution, 5/8" chuck with key
Improved spindle locking system with integrated depth stop
Laser etched downfeed scale
Paddle-style off switch with safety key
Xacta-X Laser System®, long-lasting L.E.D. light
Poly-V belt drive system, one-handed belt tensioning
Table tilts left and right 45°, tool-less tilt adjustment
Table edge designed to make clamping easy
Machine Specifications:
Drilling capacity in steel: 5/8"
Swing: 15", spindle travel: 15"
Table size: 17" x 12-1/2"
Spindle Taper: MT2/JT3
Column diameter: 2-3/4"
Weight: bench top model: 154 lb.
Spindle to table: 30-1/2"
Spindle to base: 46-1/2"
