3 HP, 1 Ph, 230 volt TEFC motor
Maximum cutting width: 11-3/4", maximum cutting depth: 3/4"
3" diameter cutting head features 42 two sided carbide cutting inserts and two rabbeting inserts
Cutterhead speed: 5,000 RPM
Precision ground cast-iron table surface
Rack and pinion adjustable fence system for smoother fence adjustments and sturdy work support
Fence size: 5-1/2"H x 47"L, tilts in and out 45°, positive stops at 45°, 90° and -45°
Parallelogram construction maintains close table-to-cutter proximity and ensures table parallelism
Dust collection requires 800 CFM, 6" outside diameter dust port
Liftgate delivery required
Includes: planer, motor, helical cutting head, tilting fence, dust port
Cutterhead guard, push blocks and tool kit
