3 HP TEFC motor with inverter, 1 Ph or 3 Ph, 220V
Electronically controlled variable speed, 40-3,500 RPM
98 indexing positions, allow for efficient and easy adjustments;
With positive locking of the spindle, open access for quick-setting changes
Magnetic backed on/off switch allows the user to move the switch anywhere on the machine
Vacuum system provides quick method of chucking bowl blanks
Air nozzle with quick connect for cleaning dust and chips
Swing over cast-iron bed: 24", swing over tool rest: 21"
Working distance between centers: 42", outboard turning: 88"
Spindle thread: 1-1/4 x 8 threads per inch, hole through spindle 5/8", hole through tailstock:
3/8", spindle lock included for convenient mounting and removal of workpiece
Headstock and tailstock taper: #2 Morse taper, slides the full length of the bed
Includes: lathe, TEFC motor with inverter, stand, safety shield, 14" tool rest, 3" face plate
Face plate wrench, tool caddy, two dead centers, two task lights
15 amp quad receptacle for easy reach of powered accessories
Brass tipped knock-out bar and magnetic backed on/off switch
