Meehanite castings
Precision honed and bored milling head
Spindle head is internally cooled
Quick spindle feed nut
Three-stage power downfeed with automatic stop
Heavy-duty spindle brake
Precision hardened and ground ways and table
Two 115 volt outlets on the electrical box for DRO or powerfeeds
Automatic lubrication every 30 minutes with a flow of 3 to 6cc reduces maintenance
Inverter drive system and emergency stop located on a swing-away arm
within the operators reach
Standard equipment: spindle safety guard, halogen machine lamp
Dual locks on all moveable surfaces, chip pan, way covers, draw bar, tool box with tools
Specifications:
Mfr. No.: 690501
Model No.: JTM-949EVS
Table Size: 9" x 49"
Spindle Taper: R8
Quill Diameter: 3-3/8"
Variable Speeds: 60-4,500 RPM
Quill Downfeed Speed Rates: .0015-.003-.006
Quill Travel": 5"
Head Movement: 90°R & L 45° F & B
Max. Distance Spindle to Table: 20-3/4"
Collet Capacity: 1/8" to 7/8"
Table Cross Travel: 12-5/8"
Travel of Ram: 15-1/4"
Inverter Type: Delta B
Motor: 3HP, 230V, 3Ph
Weight: 2,420 lbs.
