Heavy cast iron machined fence mounted on a sturdy wood table
Mortiser head features accurate rack and pinion raising and lowering system
Table and fence tilt 0-35 degrees
Easy to reach hand wheels control the linear and cross movements of the table
Base has hinged doors for storage of chisels and accessories
Standard equipment: motor, work stop, depth and length stops, enclosed stand with shelf, wood
table, drill bit adapter, quick-release vise for speedy release of work material, chuck extension
adapter, chisel and tool holder with sharpening stone, 1⁄2" drill chuck with 4" chuck key and
removable safety switch key
SPECIFICATIONS:
Motor (TEFC): 1HP/1Ph/115-230V (Prewired 115V)
Spindle Speed: 1725 RPM
Chuck Capacity: 1⁄2"
Chisel Shank Capacity (I.D.): 5⁄8", 3⁄4", 1-1⁄8"
Head Stroke: 6"
Chisel Center to Fence: 4"
Table Size: 7" x 20-1⁄4"
Base Size: 14" x 16"
Bushing size: 5⁄8", 3⁄4", 1-1⁄8"
Overall Height on Base: 60"
Shipping Weight: 292 lbs.
