15 HP, 3 Ph, 230/460 volt (pre-wired 230 volt)
Three speed feed selector: 20, 25 and 30 FPM
Segmented 3" diameter infeed roller, steel 3" outfeed roller
1⁄2 HP, 3 Ph table lift motor
Quick-set micro-adjustable lever that easily raises and lowers the table rollers from 0" to .050"
Cutterhead speed: 5,000 RPM, 30,000 cuts per minute
Number of helical head knives on cutterhead: 174 four-sided inserts, 3-3⁄8" cutterhead diameter
Maximum cutting width: 25", maximum cutting thickness: 9"
Full width cutting depth 10-3⁄8" to 25" wide: 1⁄8", for widths less than 10-3⁄8": 1⁄4"
Minimum planning length: 10"
Dust hood features an excellent dust collection system with built-in 5" dust chute
Frame machined from heavy cast iron and extra wide side panels with gibs
Offers rigid bed support and accurate alignment
Table area: 26" wide x 32-3⁄16" deep
Shipping weight: 1,850 lb.
Includes: planer, helical cutter head, dust hood with 5" dust port, segmented infeed rollers
Segmented breakers, tool kit with screwdriver for removing cutterhead insert blades
