15A, 4,800 RPM, electronic brake
Cross cut capacity at 90°: 12" horizontal, 5-1/2" vertical
Crown capacity 45° against the fence: 6"
Adjustable miter detents: 0°, 15°, 22.5°, 31.6° and 45° left and right
Positive miter stops: 0°, 15°, 22.5°, 31.6° and 45° left and right for accurate cuts
Bevel detents: 0°, 33.9° and 45° left and right
Tall sliding 4-1/4" high fences for easy bevel set-ups and increased crown cutting capacity
Chop/crown lock, locks head in place for maximum chop cutting capacity;
For upright base molding and nested crown molding
Up front bevel controls, all metal bevel lock lever and range selector for easy set-ups
Push-button detent override for fine miter adjustment
Ergonomic, ambidextrous trigger handle with soft grip, large form fitting ergonomic handle
90% dust collection efficiency
Includes: saw, carbide tipped saw blade, material clamp and dust bag
Machine Specifications:
Motor: 120V/15A
Blade Dia./Arbor: 10" x 5/8"
RPM: 4,800
Bevel Angle Range: 47° left, 48° right
Bevel Stops: 0° to 47°
Miter Angle Range: 52° left, 60° right
Weight: 64 lb.
