5HP, 1 Ph, 230V motor, 4,300 RPM, magnetic controls
12" diameter blade x 1" arbor, left tilting 0° to 45°
40-1/2" Xacta fence provides greater stability and better support
80" solid cast iron table provides a massive work service
Poly V-belt increases efficiency and reduces slipping and machine vibration
Maximum depth of cut at 90°: 4", at 45°: 2-7/8"
Maximum rip right of blade: 50", left of blade: 14", table in front of blade:12"
Maximum dado diameter: 8", maximum dado width: 13/16"
4" diameter dust port, requires 350 CFM
External tool storage for fence and miter gauge
Poly v-belt increases efficiency and reduces slipping and vibration
Includes: saw, blade, fence, miter gauge, dado insert, blade guard, riving knife
Anti-kickback pawls, table extension and legs
