Auto-LineTM Power Management Technology
Power factor of .95 enables smaller fuses/breakers and primary wiring;
Primary amperage draw at rated output is 25% less than the competition
Wind tunnel technology protects electrical components and PC boards from contamination
Fan on demand cooling system operates only when needed
Lift-arc allows TIG starting without the use of high-frequency
Starts the arc without contaminating the weld with tungsten
Adaptive hot start increases the output amperage at the start of a weld if necessary
Inverter arc control technology
Line voltage compensation keeps power constant even if power input varies by +/-10%
Process selector switch
Large, dual digital meters are easy to view and presettable to ease setting weld output
International style weld disconnects provide weld cable connections;
Two connectors supplied with each unit
Specifications:
Rated Output: 300A/32V/60% Duty Cycle; 300A/10-38V/60% Duty Cycle
Input Power: 60.8A@208V/1Ph/60Hz; 60.8A@208V/10-38V/1Ph/60Hz
